AJX-600BD Inverted Metallurgical Microscope With LWD Infinity Plan Bright & Dark Objectives
  • Specifications
  • Accessories
  • Products Catalog
  • AJX-600 AJX-600BD
    Eyepiece

    WF10×/22mm (adjustable)

    WF10×/22mm (adjustable，reticule 0.1mm)

    ●

    ●

    ●

    ●

    Metallurgical LWD Infinity Plan Objectives

    LMPlan FL 5×/0.15 W.D= 21.00mm ( Semi Apochromatic Objective )

    LMPlan FL 10×/0.30 W.D= 20.00mm ( Semi Apochromatic Objective )

    LMPlan FL 20×/ 0.40 W.D= 15.00mm ( Semi Apochromatic Objective )

    LMPlan FL 50×/0.55 W.D= 10.00mm ( Semi Apochromatic Objective )

    LMPlan FL 50×/0.75 W.D= 4.25mm ( Semi Apochromatic Objective )

    LMPlan 100× ( Dry )/ 0.85 W.D= 3.00mm ( Semi Apochromatic Objective )

    ●

    ●

    ●

    ●

    ๐

    ๐

    Metallurgical LWD Infinity
    Plan Objectives for  Bright/Dark Field

    M PLAN BD 5× /0.13 W.D= 7.30mm

    M PLAN BD 10×/0.25 W.D= 11.5mm

    M PLAN BD 20×/0.4 W.D= 5.6mm

    M PLAN BD 50×/0.7 W.D= 1.6mm

    ●

    ●

    ●

    ●

    Seidentopf Trinocular Head

    Inclined 30°, interpupillary distance: 48-76mm
    Light distribution (both):100: 0 (100% for eyepiece)
    80:20 (80% for trinocular head,and 20% for eyepiece)

    		● ●
    Nosepiece

    Quintuple

    Quadplex (specially for bright /dark field objectives )

    ●



    ●

    Mechanical Stage

    Stage size: 210 mm×180mm, Moving range:50×50mm, Scale : 0.1mm

    		● ●
    Coaxial Coarse and
    Fine Focusing unit

    Coarse stroke: 10mm,
    Fine stroke per rotation: 0.2mm, fine division 2 μm

    		● ●
    Polarizing Unit

    Polarizer /Analyzer

    		● ●
    illumination

    12V/50W Halogen（Input voltage：100V～240V）

    5WLED lamp (Input voltage：100V～240V)

    ●


    ●


    Filter

    Blue

    Green/ Amber/ Grey

    ●


    ●


    C-mount

    1×/0.75×/0.5×C-Mount  (focus adjustable)

    Adaptor for Digital Photograph

    Use for CANON／NIKON／OLYMPUS etc.

    Note:

    LMPlan FL 50×/0.55 W.D= 10.00mm ( Semi Apochromatic Objective ), suitable for applications in the fields of semiconductors, electronics, and chips

    LMPlan FL 50×/0.75 W.D= 4.25mm ( Semi Apochromatic Objective ), suitable for applications in the field of materials
