APM-10A WF10X/18mm Monocular Polarizing Microscope
  • Specifications
  • Accessories
  • Products Catalog
  • ● Eyepiece: WF10X/18mm
    ● Objective: 45mm DIN achromatic objective: 4X, 10X, 40X(S), 100(S,Oil)
    ● Monocular Head: 30°Inclined, 360°rotatable, rotatable analyzer with graduation 0°-90°, sliding out of optical path
    ● Stage: Revolving round stage: Φ160mm, 360° rotatable and graduated 1° Increments, minimum resolution 6’
    ● Condenser: ABBE condenser: N.A.1.25; Ф2-Ф30mm iris diaphragm and Ф32 Filter
    ● Focusing adjustment: Coaxial coarse and fine focusing adjustable mechanism: 14mm, precision: 0.01mm
    ● Others: Optical compensator: λSlip (first class red), 1/4 λ slip
                    Polarize: on the light collector, 360° rotatable
    ● Illumination: Built-in adjustable brightness 1W LED lamp
