The PC3-R adopts a SONY Exmor CMOS sensor as the image-picking device and USB3.0 is used as the transfer interface. The PC3-R hardware resolutions range from 1.7M to 45M and come with integrated CNC aluminum alloy compact housing.

With the two-stage Peltier cooling sensor chip to -42 degrees below ambient temperature. This will significantly increase the signal-to-noise ratio and decrease the image noise. A smart structure is designed to assure heat radiation efficiency and avoid moisture problems. An electric fan is used to increase the heat radiation speed.

The PC3-R comes with the advanced video & image processing application ToupView; Providing Windows/Linux/macOS/ Android multiple platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc);

The PC3-R can be widely used in low light environments, microscope fluorescence image capture and analysis, and the astronomy deep sky application.

OTHER HARDWARE CONFIGURATION

● Spectral Range: 380-650nm (with IR-filter), for the monochromatic camera, AR is used
● White Balance: ROI white balance/ manual temp-tint Adjustment
● Color Rendering: technique ultra fine color engine
● Capture/Control SDK: Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc)
● Recording System: still picture and movie
● Cooling System: two-stage TE-cooling System -42 °C below camera body temperature

OPERATING ENVIRONMENT
● Operating Temperature: -10 °C~ 50 °C
● Storage Temperature: -20 °C~ 60 °C
● Operating Humidity: 30~80%RH
● Storage Humidity: 10~60%RH
● Power Supply: DC 5V over PC USB Port
External Power Adapter for Cooling System, DC12V,3A

SOFTWARE ENVIRONMENT
● Operating System: Support Microsoft Windows XP / Vista / 7 /8 /10(32 & 64 bit)
OS X (Mac OS X), Linux
● PC Requirements
CPU: Equal to Intel Core2 2.8GHz or Higher
Memory: 2GB or More
USB port: USB2.0 High-speed Port
Display: 17" or Larger
CD-ROM
