PC3-RX camera adopts SONY Exmor or GSENSE with big pixel size or full-frame CMOS sensor as the image-picking device and USB3.0 is used as the transfer interface to increase the frame rate.

With the two-stage Peltier cooling sensor chip to -40°C below ambient temperature. This will significantly increase the signal-to-noise ratio and decrease the image noise. A smart structure is designed to assure heat radiation efficiency and avoid moisture problems. An electric fan is used to increase the heat radiation speed.

PC3-RX comes with advanced video & image processing application ToupView; Providing Windows/Linux/OSX multiple platform SDK; Native C/C++, C#/VB.NET, DirectShow, Twain Control API;

The PC3-RX can be widely used in low light environments, microscope fluorescence image capture and analysis, and the astronomy deep sky application.

OTHER HARDWARE CONFIGURATION
● Spectral Range: 200-1000nm (The spectral response range of each model is different. Please refer to the product manual of each model for detailed parameters)
● White Balance ROI white balance/ manual temp-tint adjustment/NA for monochromatic sensor
● Color Rendering Technique: Ultra Fine Color Engine/NA for Monochromatic Sensor
Capture/Control SDK Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc)
● Recording System: Still Picture and Movie(Free running mode or trigger mode)
● Cooling System: two-stage TE-cooling system -40 °C below camera body temperature

OPERATING ENVIRONMENT
● Operating Temperature: -10 °C~ 50 °C
● Storage Temperature: -20 °C~ 60 °C
● Operating Humidity: 30~80%RH
● Storage Humidity: 10~60%RH
● Power Supply: DC 5V over PC USB Port
External Power Adapter for Cooling System, DC12V,3A

SOFTWARE ENVIRONMENT
● Operating System Support Microsoft Windows XP / Vista / 7 /8 /10(32 & 64 bit) OS X (Mac OS X), Linux
● PC Requirements CPU:
Equal to Intel Core2 2.8GHz or Higher
Memory: 2GB or More
USB port: USB2.0 High-speed Port
Display: 17" or Larger
CD-ROM
