PCZ-2M 1x-14x 2MP 60pfs Zoom Autofocus Microscope Camera 1/2.8" Sensor With TF Card Storage Function
  • Specifications
  • Accessories
  • Products Catalog
  • Image Sensor: CMOS sensor Sony Exmor
    Sensor dimensions: 1/2.8”
    Effective pixels: 2 MP
    Pixel Size (mm): 2.9x2.9
    G sensitivity: 1300mV at 1/30sec
    ● Dark Signal: 0.34mV at 1/30sec
    ● Binning:1x1
    Output: HDMI
    Power: DC5V
    Operation control: Remote control
    Scanning: Progressive Scanning
    White balance: Manual/Auto/OnePush
    Exposure: Manual/Auto
    Shutter speed : 1/50s(1/60s)-1/10000s
    SNR: >50dB
    Frame Rate: 1080p@60fps
    Operating Temp: 0°C – 50°C
    Weight: 500g
    Optical Zoom 1x-14x
    Digital Zoom 1x-6x
    Working Distance: From 10cm to Infinity
    Focusing System: Autofocus / Manual focus
    ● Dimensions (mm): 88 x 72 x 125
    Weight (Kg): 0.57
    Working Temperature: -10°C up to +50°C
    Storage Temperature: -20°C up to +60°C
    ● Relative Humidity: 30% to 80%
    ● Storage Humidity: 10% to 60%
    ● Accessories: HDMI cable (2m), Wireless Mouse, SD card


    Magnification FOV (WD:10mm) FOV (WD:300mm)
    1x 171mm*92mm 420mm*230mm
    2x 89mm*50mm 196mm*110mm
    3x 71mm*40mm 150mm*84mm
    4x 60mm*33mm 116mm*65mm
    5x 52mm*29mm 101mm*57mm
    14x 24.3mm*13.5mm 45.5mm*25mm
