SZ-860S Infinity Parallel Galilean Optical Dual-Viewing Discussion Head Stereo Microscopes
1. Adopt the Galilean optical syste
2. Can apply for double people observatione of the same specimen simultaneously, eliminated the defects of digital teaching.
3. The built-in indicator system, display of double color in red and green, can switch as request, convenient to focus the same target
  • Specifications
  • Accessories
  • Products Catalog


  		•
    		SZ8601S
    		SZ8602S
    		SZ8603S
    Optical System
    		 Parallel optical zoom system
    		 ●
    		 ●
    		 ●
    Zoom Objective 0.8X-5X
    		 ●

    0.8X-6.5X
    		●
    0.8X-8X

    		●
    Viewing Head
    		 Binocular head, 20°inclined,Interpupilary distangce 55-75
    		 ●
    		 ●
    		 ●
    Tilting binocular eyepiece tube, 0-35°inclined, Interpupilary distangce 55-75mm ○
    		 ○
    		 ○
    Objective
    		 1X Plan achromatic objective WD= 78mm
    		 ●
    		 ●
    		 ●
    0.3X Achromatic objective WD= 276mm
    		 ○
    		 ○
    		 ○
    0.5X Achromatic objective WD= 195mm
    		 ○
    		 ○
    		 ○
    0.5X Plan apochromatic objective WD= 126mm
    		 ○
    		 ○
    		 ○
    2X Plan achromatic objective WD= 32.5mm
    		 ○
    		 ○
    		 ○
    Eyepieces
    		 Eyepiece for Main Viewing Head 10X/22mm
    		 ●
    		 ●
    		 ●
    Eyepiece for Side Viewing Head 10X/22mm
    		 ●
    		 ●
    		 ●
    Pointer
    		 Red and Green LED
    		 ●
    		●
    		 ●
    Illumination
    		 Ring illumination( LED or fluorescent)
    		 ○
    		 ○
    		 ○
    Working Distance 78mm ●
    		 ●
    		●
    Focusing Range 215mm
    		 ●
    		 ●
    		●
    Base Stage
    		 420mm x 350mm
    		 ●
    		 ●
    		 ●
    Toughened glass
    stage
    		 250mm x 250mm ●
    		 ●
    		 ●
    Optional Accessories
    		 Coaxial illumination
    		 ○
    		 ○
    		 ○
    Epi-fluorescent attachment
    		 ○
    		 ○
    		 ○
    Iris diaphragm
    		 ○
    		 ○
    		 ○
    Beamsplitter (One port)
    		 ○
    		 ○
    		 ○
    Beamsplitter (Two port)
    		 ○
    		 ○
    		 ○
    Photography & video attachment ○
    		 ○
    		 ○
    Micrometter
    		 ○
    		 ○
    		 ○
    LCD Attachment
    		 ○
    		 ○
    		 ○

    Note: ''●'' Standard Outfit   ''○'' Option
